Krem Tüp Dolum Paketleme Makinesi Üreticileri

Ürün Açıklaması:


Bu makine, gelişmiş yurtdışı teknolojisini tanıtarak ve GMP gerekliliğini entegre ederek, adil yapı, tam işlev, kolay kullanım, doğru doldurma, sabit çalışma ve düşük gürültülü özelliklerle başarılı bir şekilde geliştirilmiş ve tasarlanmış yüksek teknik ekipmandır. Otomatik olarak sıvı veya yüksek hızlı malzeme dolumundan parti numarası basımına kadar (üretim tarihini içeren) dolumda çalışan PLC denetleyicisine sahiptir, ALU tüp, plastik tüp ve kozmetik, eczane, gıda maddeleri, yapıştırıcılar vb. endüstriler, GMP standardına uygundur.
Krem Tüp Dolum Paketleme Makinesi Üreticileri

Özellikler:


1. LCD ekran PLC ve düğmeleri, kolay kullanım ve daha insancıllaştırma ile yüksek dereceli çalışma ekranı Kademeli hız ayarı, parametre ayarı, çıkış sayısı, basınç indeksi ve arıza göstergesi.
2. Tüp besleme, fotoelektrik kayıt, inert gaz dolum (isteğe bağlı), malzeme dolum ve mühürleme, parti numarası basımı, nihai ürün çıkışı otomatik olarak yürütülür.
3. Yüksek hassasiyetli fotoelektron yazıcısı renk sapmaları kapsamını azaltmıştır.
4. Ayar parçaları harici konumda, dijital göstergede, rahat ve doğru ayarlama (üreten çeşitli ürünler için uygun).
5. Mekanik, fotoelektron, elektrik, pnömatik bütünleştirici kontrol, hiçbir tüp dolum işlevine ulaşmaz; Tüp hatası pozisyonu veya basınç çok düşükse beklemek, koruyucu kapıyı açmak durumunda otomatik durdurma makinesi.
Krem Tüp Dolum Paketleme Makinesi Üreticileri

modelGF-400 AGF-400 B
Tüp malzemesiMetal boru, ALU boruPlastik tüp, bileşik tüp
Boru çapı10-42 mm10-60 mm
Tüp uzunluğu50-250 (ayarlanabilir)50-250 (ayarlanabilir)
Dolum hacmi5-500ml / dalı (Ayarlanabilir)5-800ml / dalı (Ayarlanabilir)
Doldurma doğruluğu≤ ±% 1≤ ±% 1
hız3-10 dev / dak2,5-7 dev / dak
Ürün kapasitesi30-60 Adet / dak30-60 Adet / dak
Hava besleme0.55-0.65mpa0.55-0.65mpa
Motor gücü2kw (380V / 220V 50Hz)2kw (380V / 220V 50Hz)
Isı sızdırmazlık gücü3KW3KW
Ortalama boyut2620 × 1020 × 1980 mm2620 × 1020 × 1980 mm
Makina ağırlığı1100 kg1100 kg

Temel bilgi


Uygulama: Yapıştır
Tür Oluşturma: Şişe Şekillendirme
Tahrik Tipi: Elektrik
Paketleme: Yumuşak Tüp
Motor Gücü: 2kw (380V / 220V 50Hz)
Genel Boyut: 2620 × 1020 × 1980mm
Trademark: VKPAK
Kökenli: shanghai, çin
Otomatik Sınıf: Otomatik
Tip: Dolum ve Kapama Makinesi
İşlev Oluşturma: Dolum
Malzeme Türü: Paste
Ürün Kapasitesi: 30-60 PC / Min
Isı Sızdırmazlık Gücü: 3kw
Makina Ağırlığı: 1100kg
Özellikleri: ce


A cream tube filling packing machine is a type of packaging machinery designed for filling and packaging various types of creams, gels, pastes, and other similar products into tubes. This type of machine typically consists of several components, including a tube feeder, filling unit, sealing unit, and cutting unit. The overall production process is automated, which ensures the accuracy and consistency of the fill, as well as the speed of production.

The specific features and specifications of a cream tube filling packing machine may vary depending on the manufacturer and the intended application, but some common features include:

High precision: The filling system is designed to be accurate, with the ability to fill the exact amount of product specified, with minimal waste.

Versatility: The machine can be used for filling and packaging a wide range of products, including creams, gels, pastes, and other similar products.

Hygiene: The machine is designed to meet hygiene standards, with components made from food-grade stainless steel and other non-corrosive materials. The filling system is also designed to prevent contamination, ensuring the safety and quality of the product.

Easy to operate: The machine is typically user-friendly, with intuitive controls and easy to follow instructions. The system is also designed to be easy to maintain, with minimal downtime required for cleaning and servicing.

High production rates: A cream tube filling packing machine is designed to work at high production rates, with the capability of filling and packaging hundreds or even thousands of tubes per hour.

Overall, a cream tube filling packing machine is an efficient and reliable solution for filling and packaging various types of creams and gels into tubes. It is a popular choice for manufacturers who need to package products for retail or commercial use, with the ability to meet high standards of accuracy, consistency, and hygiene.
