200L Çelik Davul Motorlu Bisiklet Yağı Dolum Makinesi Üreticisi

200L Çelik Davul Motorlu Bisiklet Yağı Dolum Makinesi Üreticisi

Tambur Dolum Makinesi, Dolum makineleri
Motorlu bisiklet yağı dolum makinesinin açıklaması: Çalışma işlemi: @ Operatör tamburu doldurucuya yerleştirir @ Operatör nozülü tambura hizalar @ Operatör ilk önce "dolum yönü" düğmesine basar, sonra "başlat" düğmesine basar. Doldurma ", dolum nozüllerinin dolması, otomatik olarak dolumun başlaması @ Ağırlık ayarına gelince, otomatik olarak dolumun durması ve nozülün tamburun dışına çıkması @ Operatör davulun dışarı itilmesi doldurma, sonra hassas doldurma. @ Malzeme ile temas eden parçalar: sus316 ve diğer parçalar için sus304 ile @ Rolling konveyör malzemesi: paslanmaz çelik @Vakum çekme sistemi,…
Daha fazla oku
Yeni Stil Sıvı Bubble Tea Drum Dolum Makinesi

Yeni Stil Sıvı Bubble Tea Drum Dolum Makinesi

Tambur Dolum Makinesi, Dolum makineleri
Main features 1. Two filling heads with separate meter and weight system and therefore two heads can work together or singly; 2. Weighing platform roller diameter 60mm, width 0.6M and length 1.78M; 3. Automatic pneumatic lifting system; 4. A capping system is available which is from Flange 2; 5. Machine outer cover is made of stainless steel. Main components 1. The metering and weighting platform if from Mettler Toledo of US and the metering system can realize computer monitor terminal. And the meter model is Panther 2000 with serial port PS422; 2. Pneumatic components are US electromagnetic directional valve and…
Daha fazla oku
Yağ Varil Dolum Makinesi

Yağ Varil Dolum Makinesi

Tambur Dolum Makinesi, Dolum makineleri
Features 1) The drum filling machine is widely used for filling medium and small capacity liquid with various viscosities. It is the bottom-filling type 2) Automatically subtracting weight of container 3) Arbitrarily sets filled liquid weight in design of weighing scope 4) Automatically controls filling at fast or slow speed to prevent over washing 5) Displays statistic data, such as accumulate filling frequency and total filling weight 6) Possesses printer output interface 7) Adopts USA Medl-Toredo weight instruments and sensors Main technical parameters 1) Filling weight: 50 - 400kg 2) Production capacity: 40 - 60 barrels/hour (180kg/barrel) 3) Weighing error:…
Daha fazla oku
200kg Davul Dolum Makinası

200kg Davul Dolum Makinası

Tambur Dolum Makinesi, Dolum makineleri
FEATURES 1. Filling Method: Filling from top. (can be product from bottom , control bubble ) 2. Control Mode: Manual setting filling way, micro switch control. 3. Conveying Mode: Roller Type Conveying without engine. 4. Own digital displaying filling quantity function, can finish multi-kinds filling quantity setting. 5. Automatic peeled, based on net weight filling function. 6. Own vacuum withdrawing function to avoid anti-drip. 7. With manual & automatic micro switch control system function. 8. Dual speed control function to prevent splashing. 9. With emergent treatment to avoid misuse and protect power-off. Range 20-200kg Filling Speed 40-60drum/hour Filling Accuracy ±0.1%…
Daha fazla oku
200L Davul Sıvı Dolum Makinesi

200L Davul Sıvı Dolum Makinesi

Tambur Dolum Makinesi, Dolum makineleri
Drum Liquid Filling Machine Suitable for quantitative filling of chemical industry, food, medical industry The system uses PLC, touch screen, safe and reliable Filling nozzle and pipe use quick coupling, convenient for removing and washing Automatic 2-shift filling with high accuracy The filling nozzle automatically lifts when it is not inserted into a barrel The nozzle automatically lifts when reaching the target filling amount Gross or net filling mode is available Be able to set and store 30 groups of formula for use Free to set target filling amount in order to be convenient for different packing Filling with one…
Daha fazla oku
IBC DRUM DOLUM MAKİNESİ

IBC DRUM DOLUM MAKİNESİ

Tambur Dolum Makinesi, Dolum makineleri
Specification of Machine l Model No.: NPACK-1200L1 l Filling Material: lubricating oil/Resin/ Engine oil l Filling Weight: 1000kg/IBC DRUM l Filling Capacity: 1000L IBC DRUM l Filling Accuracy: ±0.1% F.S. (Accuracy depends on suitable adjustment of slow feeding and the stability and consecutiveness of liquid to spray gun l Filling Speed: 10 IBC DRUMS/hour (Depend on previous speed of feeding material, the previous speed of liquid must be 300L/MIN.) l Measure Method: Two-section Feed Control, Filling into drum on above liquid level l Material Connector: DN40 Rapid Flange Connector (Pressure of liquid feeding should less than 0.6MPa) Machine Details 2.1…
Daha fazla oku
Özelleştirilebilir ESDF Serisi 100-1000L Kapasiteli Büyük Tamburlu Otomatik Dolum Makinesi

Özelleştirilebilir ESDF Serisi 100-1000L Kapasiteli Büyük Tamburlu Otomatik Dolum Makinesi

Tambur Dolum Makinesi, Dolum makineleri
Product Introduction It adopts gravimetric method to measure, by weighing sensor output signal to control the charging valve opening, so as to realize the purpose the purpose of automatic filling. By equipped with a pump in the front end of the feeding port, or pressuring the material tanks Sent material from tank to the filling machine. The filter device can be added before filling to guarantee the quality of products. It has the advantage of high efficiency and small filling error, it's widely used in coating, ink, paint, asphalt, glue, lubricant, petrochemical, fineness chemical industries. It is not only suitable…
Daha fazla oku
