PET şişe için üçü bir arada makine, durulama, doldurma ve kapatma işlevini bir araya getirir. Yurtdışındaki ileri teknolojiye dayanan ve su doldurma işleme taleplerine göre tasarlanmış
Ana Özellikler
1. This machine has a compact structure, completed control system, easy to operate and highly automated.
2. By changing the star-wheel, screw bottle inlet and arc guide plate can realize to change the bottle shape.
3. The parts that direct contact with product are made of food grade stainless steel and no technology corner pockets and easy to clean.
4. By adopting high speed filling valve, the liquid level is precise and no waste. That guarantees the demand of filling technology.
5. The machine adopts high effective cap sorting system and completely self control and protective device.
6. The machine is equipped with perfect overload protective device that can keep the equipment and operator safely.
7. The control system has many functions, such as control producing speed, cap shortage detection, bottle block automatic stop and production counting etc.
8. The electric components and pneumatic components are all introduced from world famous brand products.
Çalışma pozisyonu miktarı | Durulama 32, doldurma 32, kapatma 10 |
Üretim kapasitesi | 15000BPH (500 mi) |
Hava kaynağının basıncı | 0.7Mpa |
Hava tüketimi | 1.2m3 / dakika |
Durulama suyu basıncı | 0.2-0.25Mpa |
Durulama suyu kapasitesi | 2.5T / H |
Ana motor gücü | 3.2kW |
Toplam güç | 4.8kw |
boyut | 4250X2150X2200mm (L × G × Y) |
ağırlık | 5200kg |
Ayrıca Komple Otomatik Saf Su Şişeleme Tesisi sağlıyoruz
4 ana parçadan oluşur:
1. Plastic bottle blow molding machine
2. Water cleaning system
3. Water washing, filling, capping machine.
4. Conveyor system, labeling machine, dating machine, film wrapping machine
Tam çizgi ana açıklaması:
1. The plant can produce different volume bottles, from 200ml to 2000ml bottles, round and square bottles, plastic and glass bottles. It is very easy to change the different bottle molds.
2. The plant is highly automatic, you can operate on the touch screen to adjust the machine speed and working.
3. We have different speed plants, commonly, 2000BPH, 4000BPH, 7000BPH, 10,000BPH, 15000BPH..ect.
4. The material is stainless steel 304, food grade much clean and safe.
5. We provide the engineers for customer installation, training in customer's factory.
Modeller ve Hız Listesi
model | XGF8-8-3 | XGF14 / 12/5 | XGF16 / 16/5 | XGF24 / 24/8 | XGF32 / 32/10 |
Elleri yıkamak | 8 | 14 | 16 | 24 | 32 |
Dolum vanaları | 8 | 12 | 16 | 24 | 32 |
Eller kapatma | 3 | 5 | 5 | 8 | 10 |
Uygun PET / Cam Şişeler (150ml ila 2000ml) | |||||
Kapasite (Hız) 500ml baz | 2000BPH | 5000BPH | 7000BPH | 12000BPH | 15000BPH |
Elektrik bileşenleri marka tedarikçi
Ana kompozisyon | Açıklama Tedarikçi |
PLC | Mitsubishi (Japonya), Siemens (Almanya) |
Dokunmatik ekran | WEINVIEW (Tayvan) |
Frekans dönüştürücü | Mitsubishi (Japonya), Siemens (Almanya) |
Hava düğmesi | Schneider (Fransa) |
kırıcı | Siemens (Almanya) |
devre açıcı | Siemens (Almanya) |
Fotoelektrik anahtarı | Omron (Japonya) |
Hızlı Ayrıntılar
Tip: Dolum Makinesi
Durum: Yeni
Uygulama: İçecek, Kimyasal, Tıbbi
Ambalaj Türü: Şişeler
Ambalaj Malzemesi: Plastik
Otomatik Sınıf: Otomatik
Tahrik Tipi: Elektrik
Gerilim: 380V / 220V
Güç: 4.8KW
Menşe Yeri: Çin (Anakara)
Marka Adı: NPACK
Boyut (L * W * H): 4250X2150X2200mm
Ağırlık: 5200KGS
Belgelendirme: ce, iso, sgs
Sağlanan Satış Sonrası Hizmet: Yurtdışı hizmet amaçlı kullanılabilir makine mühendisleri
Fabrika: BAĞLANTILAR MAKINESI
Şişe Boyutu: 150ml ila 2000ml
Şişe Boyu Çapı: 15-55mm
Şişe Malzemesi: Plastik / Cam
Hız (500ml şişede baz): 15000B / H
Kontrol Sistemi: PLC Dokunmatik Ekran (MITSUBISHI JAPONYA)
Kapak: vida / basın kapağı
Kapak asansör: var
Sıvı Dolum: Maden / Saf Su
